C POS
◇ Robust & Stylish 15.6” All-in-one POS Terminal integrated with a widevariety of peripherals. ◇ Foldable structure design in a compact size to save Total Logistics Cost(TLC). ◇ Motherboard designed as proprietary form factor to support diverse intel CPU platforms. ◇ Display tilt angle 0-180 degree. ◇ Standard VESA holes to support various mounting ways. ◇ Custom made colorful base/hinge/side covers.
| Main Board Name | MA1N |
| CPU | Alder Lake-N N97, N300 or N305 |
| System Memory | SO-DIMM 1 x DDR4, Up to 16GB |
| Size | 15.6" |
| Brightness | 1366 x 768 (220nits) , Optional 1920 x1080 (250nits / 300nits) |
| Resolution | 1366 x 768 (220nits) , Optional 1920 x1080 (250nits / 300nits) |
| Touch Screen | PCT (Projected Capacitive Touch) Support 10 points Multi Touch |
| HDD or SSD | 1 x m.2 2280 M-key slot |
| - | Optional 802.11 ac/a/b/g/n Wireless module (m.2 2230) |
| COM Port | 2 x RS232 (RJ-50) RI / 5 / 12V select by BIOS Optional RJ50 to DB9 convert cable (COM Port) |
| USB | 6 x USB3.0, 2 x USB-C Option Internal x USB 2.0 on 10pin header |
| Cash Drawer | 1 x Cash Drawer supported 12V or DC-IN Voltage 19V/24V select by Jumper |
| Audio Jacks | 1x 3.5 mm headphone and microphone combo jack |
| Giga LAN | 1 x 2.5Giga LAN |
| LED | 1 x Power |
| Power Switch | 1 x Power On/Off switch |
| Dimension ( WxDxH ) | 400.9 (W) x 232.3 (D) x 250.2 (H) mm / 15.8 (W) x 9.1 (D) x 9.9 (H) inch |
| Net Weight / Gross Weight | G.W. 5 Kg / 11 lbs N.W. 4 Kg / 8.8 lbs |
| Adaptor | 65W (19V/3.42A) |
| Mounting mechanism | VESA 75 x 75 mm |
| Certifications | CE , LVD , FCC , VCCI |
| Operating Temperature | 0~40℃ ( 32~104℉) |
| Storage environment | -20~60℃ ( -4~140℉) |
| Safety Compliance | CE , LVD , FCC , VCCI |
| Part No. | Description |
| Part No. | Description |
